PILOT #5 Turbine Blade via LPBF

Tabs

 Rethinking the trade-off between material efficiency and machinability — from powder to finished blade.

The Challenge

Turbine blades are among the most demanding components in aerospace and energy applications. Manufactured from nickel superalloys — materials selected for their resistance to extreme heat and mechanical stress — they are typically produced from solid billets through intensive subtractive machining. In aerospace manufacturing, the buy-to-fly ratio (the mass of the starting billet relative to the mass of the finished part) can exceed 10, meaning that over 90% of raw material is removed as chips. This generates significant waste of costly feedstock, in addition to the energy and emissions associated with machining.

Laser Powder Bed Fusion offers a path toward near-net-shape production: parts built close to their final geometry, reducing the machining stock required. But near-net-shape does not mean zero machining. Thin-walled components such as turbine blades present a specific challenge: the relationship between AM build offset and downstream milling stability is not yet well understood. Too little offset, and post-processing becomes difficult or impossible. Too much, and the material savings are lost. This gap — sitting precisely at the interface between additive and subtractive manufacturing communities — is what Pilot #5 directly investigates.

THE DIAMETER APPROACH

Circularity strategy

Near-net-shape manufacturing to reduce material input and machining waste; LCA-based sustainability assessment across the full AM and post-processing chain

AM process

 Laser Powder Bed Fusion (LPBF)

Fraunhofer IPT and Fraunhofer IWU (Germany), together with Valland S.p.A. (Italy), are investigating the production of a single turbine blade in Inconel 718 via LPBF. The pilot is designed to characterise the LPBF process across two different machines, generating comparable datasets that feed process models and lifecycle sustainability assessments.

The central research question is finding the optimal build offset: enough material for stable milling, as little as possible to limit feedstock consumption and machining time. Both partners run the same material and process setup in parallel, enabling cross-machine comparison under controlled conditions.

PARTNERS INVOLVED

Process owner and demonstration lead. LPBF production, final part characterisation, milling/post-processing, machining stability trials

Use case owner. LPBF part production; test specimens, density and mechanical characterisation samples

EXPECTED OUTCOMES

  • Validated near-net-shape LPBF process parameters for Inconel 718 turbine blade geometry
  • Mechanical characterisation data: tensile properties, density, surface quality, geometric accuracy, profile deviation
  • Quantified analysis of the trade-off between AM build offset and milling stability for thin-walled nickel superalloy parts
  • Cross-machine comparative dataset from two LPBF machines operating on the same material and setup
  • Full LCA of the LPBF + machining process chain, including energy, inert gas, and material consumption data
  • Part and process data structured for EU Digital Product Passport (EU DPP) integration

STATUS: IN PROGRESS

Parts in Inconel 718 have been produced by both Fraunhofer and Valland across multiple build jobs, generating samples for mechanical testing, density measurement, and geometric accuracy assessment. A common geometry has been produced and heat-treated; shipping for machining is planned. Turbine blade plates have been sent to Fraunhofer IPT for milling; an allowance discrepancy at the blade tip is being evaluated — feasibility of post-processing the existing parts is under assessment, with a corrected build job as a fallback. Energy, gas, and material consumption data has been collected and shared with Strategem for LCA modelling. Machining trials on the blade geometry are ongoing at Fraunhofer IPT and IWU, with mechanical characterisation expected to complete in early 2026.

This section will be updated as the pilot advances
